Larger impact everywhere but the budget
UDE series 46″/55″ thin bezel
Commercial LED LCD Displays
Make sure all the attention is on your videowall, and not on the space in between. The cost-friendly Samsung UDE Series offers videowall displays with thin bezels to fit every budget and need. The UDE-C Series features a bezel-to-bezel width of just 5.5mm, while the UDE-B Series offers a total bezel width of just 3.5mm. Videowalls are impressive, impactful and virtually seamless. Additionally, the UDE-B and UDE-C Series offer 4K UHD resolution for up to 25 displays when daisy chained, with no scalers or distribution boxes required. Maximum impact in boardrooms, retail spaces public places and more. The budget-conscious Samsung UDE Series commercial displays.
Ultra-slim bezels, virtually seamless videowalls
The minimized total bezel-to-bezel width of just 3.5mm or 5.5mm is crucial to the virtually seamless video wall experience that the UDE Series delivers. UDE Series displays are ideal for a range of environments and applications, including control rooms, the medical sector, conference rooms, broadcasting stations, transportation hubs, lobbies and retail.
Advanced Color Expert factory calibration
UDE Series displays are meticulously factory tuned for Brightness, Color Temperature and Gamma. The advanced Samsung Color Expert algorithm ensures outstanding, optimal uniformity and impressive images right out
of the box. Calibration time is reduced, and videowalls are nothing short
of spectacular.
Advanced color management
UDE-C displays allow you to fine-tune color even more precisely through Samsung’s new Advanced Color Management solution. A user-friendly interface makes detailed color adjustments simple.
DisplayPort 1.2
The DisplayPort 1.2 digital loop out feature allows you to easily share content across videowalls, and fully supports Ultra High Definition resolution. It’s an easy and cost-effective way to connect multiple displays.
Direct-lit LED
Direct-lit LED technology with a new backlight dimming solution allows the UDE Series displays to achieve deeper blacks, higher contrast ratio of 3500:1, and power savings of up to 30%.
Full UHD 4K resolution
UDE displays feature 4K resolution to give you Full UHD videowalls of up to 25 displays, when daisy-chained together. Image clarity and detail is spectacular.
UD46E-B | UD55E-B | UD46E-C | ||
Display | Screen Size | 46" | 55" | 46" |
Panel Technology | Direct-lit LED Backlit LCD | Direct-lit LED Backlit LCD | Direct-lit LED Backlit LCD | |
Resolution | 1920 x 1080 (16:9) | 1920 x 1080 (16:9) | 1920 x 1080 (16:9) | |
Brightness | 500 nits | 500 nits | 500 nits | |
Contrast Ratio (Typical) | 3500:1 | 4000:1 | 3500:1 | |
Viewing Angle (Horizontal/Vertical) | 178/178 | 178/178 | 178/178 | |
Orientation | Landscape / Portrait | Landscape / Portrait | Landscape / Portrait | |
Response Time | 8ms | 8ms | 8ms | |
Connectivity | Input | Analog D-SUB, DVI-D, DisplayPort 1.2, HDMI1, HDMI2, Stereo Mini Jack, USB (Only for F/W upgrades) | ||
Output | DisplayPort 1.2, (Loop Out) Stereo Mini Jack | DisplayPort 1.2, (Loop Out) Stereo Mini Jack | DisplayPort 1.2, (Loop Out) Stereo Mini Jack | |
External Control | RS232C (In/Out), RJ45 | RS232C (In/Out), RJ45 | RS232C (In/Out), RJ45 | |
External Sensor | Detachable Type (IR, Ambient) | Detachable Type (IR, Ambient) | Detachable Type (IR, Ambient) | |
Power | Power Supply | AC 100 - 240 V~ (+/- 10 %), 50/60 Hz | AC 100 - 240 V~ (+/- 10 %), 50/60 Hz | AC 100 - 240 V~ (+/- 10 %), 50/60 Hz |
Power Consumption (Typical/Max) | 87W / 143W | 136W / 198W | 93W / 143W | |
Power Consumption (Standby) | < 0.5W | < 0.5W | < 0.5W | |
Environmental Conditions | Operating Temperature | 0°C - 40°C | 0°C - 40°C | 0°C - 40°C |
Operating Humidity | 10%~80% | 10%~80% | 10%~80% | |
Features | Special | Hardware | Anti Retention (Haze 44%), Temperature Sensor, RS232C/RJ45 MDC, Plug and Play (DDC2B), Videowall (15x15 (OSD)), Videowall Daisy Chain (10x10), Pivot Display, Button Lock, DP 1.2 Digital Daisy Chain (Supporting UHD Resolution, HDCP support), Clock Battery (80hrs Clock Keeping) | |
Software | ACM Support (Advanced Color Management), Auto Source Switching & Recovery, Image Rotation, Smart F/W update | |||
Internal Media Player | N/A | N/A | N/A | |
VESA Standard Wall Mount Interface | 600 x 400mm | 600 x 400mm | 600 x 400mm | |
Dimensions | Product Dimensions (without stand) | 40.2" x 22.7" x 3.8" | 47.8" x 26.9" x 3.8" | 40.3" x 22.8" x 4.5" |
Packaging Dimensions | 45.7" x 28.1" x 11.0" | 57.1" x 35.6" x 15.2" | 45.1" x 27.2" x 11.0" | |
Bezel Width | 2.3mm (U/L), 1.2mm (R/B) | 2.3mm (U/L), 1.2mm (R/B) | 3.7mm (U/L), 1.8mm (R/B) | |
Weight | Product Weight | 39.6 lbs. | 51.3 lbs. | 39.6 lbs. |
Shipping Weight | 49.3 lbs. | 81.2 lbs. | 77.0 lbs. | |
Service | Standard Warranty | 3 Years On-Site (Parts / Labor / Backlight) | ||
Accessories | Included | Quick Setup Guide, Warranty Card, Application CD, D-sub Cable, Power Cord, Remote Controller, Batteries | ||
Optional Mount | WMN-46VD | WMN-55VD | WMN-46VD | |
Optional Stand | MID-UD46DS (Videowall Floor Stand) | MID-UD55DS (Videowall Floor Stand) | MID-UD46FS (Videowall Floor Stand) | |
Optional Media Player | SBB-DA, SBB-DI, SBB-B32D | SBB-DA, SBB-DI, SBB-B32D | SBB-DA, SBB-DI, SBB-B32D | |
Green Management | Emission Standard | EMC | EMC | EMC |
ENERGY STAR® 6.0 Compliant | Yes | Yes | Yes | |
RoHS Compliant | Yes | Yes | Yes | |
Packaging Recyclability | Packing Materials Recyclable | Packing Materials Recyclable | Packing Materials Recyclable | |
